Figure 106 illustrates an instance diagram.
Figure 106 — Bounded Value |
<?xml version="1.0"?>
<ConceptTemplate xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" uuid="3d67a2d2-761d-44d9-a09e-b7fbb1fa5632" name="Bounded Value" status="sample" owner="System" applicableSchema="IFC4" applicableEntity="IfcPropertyBoundedValue">
<Rules>
<AttributeRule RuleID="PropertyName" AttributeName="Name">
<EntityRules>
<EntityRule EntityName="IfcIdentifier" />
</EntityRules>
</AttributeRule>
<AttributeRule AttributeName="Description">
<EntityRules>
<EntityRule EntityName="IfcText" />
</EntityRules>
</AttributeRule>
<AttributeRule RuleID="UpperValue" AttributeName="UpperBoundValue">
<EntityRules>
<EntityRule EntityName="IfcValue" />
</EntityRules>
</AttributeRule>
<AttributeRule RuleID="LowerValue" AttributeName="LowerBoundValue">
<EntityRules>
<EntityRule EntityName="IfcValue" />
</EntityRules>
</AttributeRule>
<AttributeRule RuleID="SetValue" AttributeName="SetPointValue">
<EntityRules>
<EntityRule EntityName="IfcValue" />
</EntityRules>
</AttributeRule>
</Rules>
</ConceptTemplate>
