8.11.2.58 IfcModulusOfSubgradeReactionMeasure
8.11.2.58.1 Semantic definition
IfcModulusOfSubgradeReactionMeasure is a geotechnical measure describing interaction between foundation structures and the soil. May also be known as bedding measure.
Usually measured in N/m3.
Type: REAL
Figure 8.11.2.58.A illustrates elastic support of a planar member.
8.11.2.58.2 Formal representation
TYPE IfcModulusOfSubgradeReactionMeasure = REAL;
END_TYPE;
