Natural language names
 | Mannschaft - Ressource |
 | Crew Resource |
 | Équipe |
| Mannschaft - Ressource |
| Crew Resource |
| Équipe |
| Item | SPF | XML | Change | Description | IFC2x3 to IFC4 |
|---|---|---|---|---|
| IfcCrewResource | ||||
| OwnerHistory | MODIFIED | Instantiation changed to OPTIONAL. | ||
| Identification | X | MODIFIED | Name changed from ResourceIdentifier to Identification. | |
| LongDescription | MODIFIED | Name changed from ResourceGroup to LongDescription. Type changed from IfcLabel to IfcText. | ||
| Usage | X | X | MODIFIED | Name changed from ResourceConsumption to Usage. Type changed from IfcResourceConsumptionEnum to IfcResourceTime. |
| BaseCosts | X | X | MODIFIED | Name changed from BaseQuantity to BaseCosts. Type changed from IfcMeasureWithUnit to IfcAppliedValue. Aggregation changed from NONE to LIST. |
| BaseQuantity | ADDED | |||
| PredefinedType | ADDED |
IfcCrewResource represents a collection of internal resources used in construction processes.
HISTORY New entity in IFC2.0.
Identification of people and equipment of a crew is achieved through their specification at the level of the component. Therefore, knowing which persons are within a crew is achieved through identifying the persons assigned to each IfcLaborResource within the IfcCrewResource. Similarly, identifying that a screwing machine for pipe fitting forms part of the crew is achieved by relating an appropriate instance of IfcElementComponent to the IfcConstructionEquipmentResource forming an element of the IfcCrewResource.
| # | Attribute | Type | Cardinality | Description | C |
|---|---|---|---|---|---|
| 11 | PredefinedType | IfcCrewResourceTypeEnum | [0:1] | Defines types of crew resources. | X |
| # | Attribute | Type | Cardinality | Description | C |
|---|---|---|---|---|---|
| IfcRoot | |||||
| 1 | GlobalId | IfcGloballyUniqueId | [1:1] | Assignment of a globally unique identifier within the entire software world. | X |
| 2 | OwnerHistory | IfcOwnerHistory | [0:1] |
Assignment of the information about the current ownership of that object, including owning actor, application, local identification and information captured about the recent changes of the object,
NOTE only the last modification in stored - either as addition, deletion or modification. | X |
| 3 | Name | IfcLabel | [0:1] | Optional name for use by the participating software systems or users. For some subtypes of IfcRoot the insertion of the Name attribute may be required. This would be enforced by a where rule. | X |
| 4 | Description | IfcText | [0:1] | Optional description, provided for exchanging informative comments. | X |
| IfcObjectDefinition | |||||
| HasAssignments | IfcRelAssigns @RelatedObjects | S[0:?] | Reference to the relationship objects, that assign (by an association relationship) other subtypes of IfcObject to this object instance. Examples are the association to products, processes, controls, resources or groups. | X | |
| Nests | IfcRelNests @RelatedObjects | S[0:1] | References to the decomposition relationship being a nesting. It determines that this object definition is a part within an ordered whole/part decomposition relationship. An object occurrence or type can only be part of a single decomposition (to allow hierarchical strutures only). | X | |
| IsNestedBy | IfcRelNests @RelatingObject | S[0:?] | References to the decomposition relationship being a nesting. It determines that this object definition is the whole within an ordered whole/part decomposition relationship. An object or object type can be nested by several other objects (occurrences or types). | X | |
| HasContext | IfcRelDeclares @RelatedDefinitions | S[0:1] | References to the context providing context information such as project unit or representation context. It should only be asserted for the uppermost non-spatial object. | X | |
| IsDecomposedBy | IfcRelAggregates @RelatingObject | S[0:?] | References to the decomposition relationship being an aggregation. It determines that this object definition is whole within an unordered whole/part decomposition relationship. An object definitions can be aggregated by several other objects (occurrences or parts). | X | |
| Decomposes | IfcRelAggregates @RelatedObjects | S[0:1] | References to the decomposition relationship being an aggregation. It determines that this object definition is a part within an unordered whole/part decomposition relationship. An object definitions can only be part of a single decomposition (to allow hierarchical strutures only). | X | |
| HasAssociations | IfcRelAssociates @RelatedObjects | S[0:?] | Reference to the relationship objects, that associates external references or other resource definitions to the object.. Examples are the association to library, documentation or classification. | X | |
| IfcObject | |||||
| 5 | ObjectType | IfcLabel | [0:1] |
The type denotes a particular type that indicates the object further. The use has to be established at the level of instantiable subtypes. In particular it holds the user defined type, if the enumeration of the attribute PredefinedType is set to USERDEFINED.
| X |
| IsDeclaredBy | IfcRelDefinesByObject @RelatedObjects | S[0:1] | Link to the relationship object pointing to the declaring object that provides the object definitions for this object occurrence. The declaring object has to be part of an object type decomposition. The associated IfcObject, or its subtypes, contains the specific information (as part of a type, or style, definition), that is common to all reflected instances of the declaring IfcObject, or its subtypes. | X | |
| Declares | IfcRelDefinesByObject @RelatingObject | S[0:?] | Link to the relationship object pointing to the reflected object(s) that receives the object definitions. The reflected object has to be part of an object occurrence decomposition. The associated IfcObject, or its subtypes, provides the specific information (as part of a type, or style, definition), that is common to all reflected instances of the declaring IfcObject, or its subtypes. | X | |
| IsTypedBy | IfcRelDefinesByType @RelatedObjects | S[0:1] | Set of relationships to the object type that provides the type definitions for this object occurrence. The then associated IfcTypeObject, or its subtypes, contains the specific information (or type, or style), that is common to all instances of IfcObject, or its subtypes, referring to the same type. | X | |
| IsDefinedBy | IfcRelDefinesByProperties @RelatedObjects | S[0:?] | Set of relationships to property set definitions attached to this object. Those statically or dynamically defined properties contain alphanumeric information content that further defines the object. | X | |
| IfcResource | |||||
| 6 | Identification | IfcIdentifier | [0:1] | An identifying designation given to a resource. It is the identifier at the occurrence level. | X |
| 7 | LongDescription | IfcText | [0:1] | A detailed description of the resource (e.g. the skillset for a labor resource). | X |
| ResourceOf | IfcRelAssignsToResource @RelatingResource | S[0:?] | Set of relationships to other objects, e.g. products, processes, controls, resources or actors, for which this resource object is a resource. | X | |
| IfcConstructionResource | |||||
| 8 | Usage | IfcResourceTime | [0:1] | Indicates the work, usage, and times scheduled and completed. Some attributes on this object may have associated constraints or time series; see documentation of IfcResourceTime for specific usage. If the resource is nested, then certain values may be calculated based on the component resources as indicated at IfcResourceTime. | X |
| 9 | BaseCosts | IfcAppliedValue | L[1:?] | Indicates the unit costs for which accrued amounts should be calculated. Such unit costs may be split into Name designations (for example, 'Standard', 'Overtime'), and may contain a hierarchy of cost values that apply at different dates (using IfcCostValue.ApplicableDate and IfcCostValue.FixedUntilDate). | X |
| 10 | BaseQuantity | IfcPhysicalQuantity | [0:1] | Identifies the base quantity consumed of the resource relative to assignments. For crew, labour, subcontract, and equipment resources, this refers to IfcQuantityTime. For material resources, this refers to IfcQuantityVolume. For product resources, this refers to IfcQuantityCount. | X |
| IfcCrewResource | |||||
| 11 | PredefinedType | IfcCrewResourceTypeEnum | [0:1] | Defines types of crew resources. | X |
Object Typing
The Object Typing concept applies to this entity as shown in Table 305.
| |||
Table 305 — IfcCrewResource Object Typing |
| # | Concept | Model View |
|---|---|---|
| IfcRoot | ||
| Software Identity | Common Use Definitions | |
| Revision Control | Common Use Definitions | |
| IfcObject | ||
| Object Occurrence Predefined Type | Common Use Definitions | |
| IfcConstructionResource | ||
| Document Association | Common Use Definitions | |
| Constraint Association | Common Use Definitions | |
| Property Sets for Objects | Common Use Definitions | |
| Object Nesting | Common Use Definitions | |
| IfcCrewResource | ||
| Object Typing | Common Use Definitions | |
Instance diagram <xs:element name="IfcCrewResource" type="ifc:IfcCrewResource" substitutionGroup="ifc:IfcConstructionResource" nillable="true"/>
<xs:complexType name="IfcCrewResource">
<xs:complexContent>
<xs:extension base="ifc:IfcConstructionResource">
<xs:attribute name="PredefinedType" type="ifc:IfcCrewResourceTypeEnum" use="optional"/>
</xs:extension>
</xs:complexContent>
</xs:complexType>
ENTITY IfcCrewResource
SUBTYPE OF (IfcConstructionResource);
PredefinedType : OPTIONAL IfcCrewResourceTypeEnum;
WHERE
CorrectPredefinedType : NOT(EXISTS(PredefinedType)) OR
(PredefinedType <> IfcCrewResourceTypeEnum.USERDEFINED) OR
((PredefinedType = IfcCrewResourceTypeEnum.USERDEFINED) AND EXISTS (SELF\IfcObject.ObjectType));
END_ENTITY;
